New Phase-Shaping Technique Eliminates Speckles in Holographic Imaging and Lithography

Breakthrough in Holographic Technology

Researchers have developed a novel approach to eliminate the persistent problem of speckles in holographic imaging, according to a recent study published in Nature Communications. The new method, based on phase-probability shaping, reportedly enables the reconstruction of holographic images with ultralow speckle contrast and record-high edge sharpness, potentially revitalizing applications in optical display and lensless lithography.

The Speckle Problem in Holography

Since its invention in 1948, optical holography has been plagued by speckles—random bright and dark spots that degrade image quality, sources indicate. These artifacts originate from intrinsic fluctuations caused by irregular complex-field superposition, analysts suggest. Despite various averaging techniques including spatial, temporal and spectral methods, holographic images have struggled to achieve the homogeneity and sharpness required for advanced applications in display technology and lithography.

The report states that conventional speckle reduction methods typically involve averaging multiple incoherent speckles, but these approaches come with significant drawbacks. “These averaging techniques can reduce the speckles efficiently but at the cost of blurred edges, missing details or time-consuming exposure,” the researchers noted in their publication.

Phase-Probability Shaping Solution

The breakthrough came from investigating the statistical properties of holographic phase, according to the research team. They discovered that speckle contrast could be theoretically suppressed to nearly zero by narrowing the probability density distribution of encoded phase, even under high-coherence illumination. This physical insight guided the development of their Adam-gradient-descent probability-shaping (APS) method.

“Optical speckles can be suppressed by reducing the width of the phase probability distribution in the mask,” the report states, highlighting the fundamental principle behind their speckle-free holograms. The method specifically excludes uniform probability distribution in the phase mask during hologram design, which had previously been a standard approach.

Algorithm Development and Performance

The APS algorithm incorporates three key features, according to the researchers: an iteration method based on Adam gradient descent, a hybrid loss function evaluating multiple image quality parameters, and dynamic weighted coefficients to control singularity features. Through 1500 iterations, the algorithm can generate holograms with significantly reduced speckles while maintaining image fidelity.

Experimental results demonstrated remarkable performance improvements, analysts suggest. The researchers achieved experimental reconstruction of irregular images with ultralow speckle contrast (C = 0.08) compared to conventional methods (C = 0.50). The full width at half maximum of normalized intensity probability density was approximately one order of magnitude smaller than that achieved with traditional Gerchberg-Saxton algorithms.

Advanced Lithography Applications

The technology’s potential was demonstrated through lensless lithography applications, reportedly enabling experimental fabrication of arbitrary-shape and edge-sharp patterns with spatial resolution of 0.54λ/NA. This corresponds to feature sizes of 310 nm using 405 nm wavelength light, approaching the diffraction limit.

Edge sharpness reached approximately 1000 mm⁻¹, representing nearly a 100-fold enhancement compared to the latest reported sharpness via spatial-mode average, according to the research. “Such a giant enhancement originates fundamentally from our high-coherence and single-mode reconstruction via phase-probability shaping,” the researchers explained, noting that none of the previous averaging or filtering methods were included in their approach.

Implementation and Broadband Performance

The team utilized geometric metasurfaces composed of rotating dielectric nanobricks to realize the phase masks, fabricated via standard electron-beam lithography with dry-etching processes. Due to the dispersion-less properties of these metasurfaces, the speckle-free features remained valid over a wide spectrum, maintaining nearly constant performance near 633 nm wavelength.

The report suggests that by using larger-size metasurfaces offering higher spatial frequencies for holographic reconstruction, edge sharpness could be further enhanced to fabricate even finer patterns in optical lithography. This development potentially offers a competitive alternative to existing lithographic approaches, particularly given its lensless operation without complicated projection systems and comparable resolution at single exposure.

Future Implications

This breakthrough in phase-probability shaping addresses a fundamental limitation that has constrained holography applications for decades, analysts suggest. The ability to produce speckle-free holographic images with sharp edges and high resolution could significantly impact fields including optical display, lithography, and potentially biomedical imaging.

The researchers emphasize that their method provides a fundamentally different approach to speckle reduction compared to conventional techniques. Rather than averaging out speckles through coherence control, their method prevents speckle formation at its statistical origin, potentially opening new avenues for high-quality holographic applications across multiple industries.
